Purpose

Y-Type Strainers are typically used in application where the amount of solids to be removed is small, and where frequent clean – out is not required.

They are most commonly used in pressurized lines, gas or liquid, but can also be used in suction or vacuum conditions.

“Y” Strainer mechanically removing solids from flowing liquids, Air, Steam or gases by means of a perforated or wire mesh straining element.

OPERATING PRINCIPLES

Y-Strainer has the advantage of being able to be installed in either a horizontal or vertical position.

The screening element or “leg” must be on the “downside” of the strainer body so that entrapped solids can be properly collected and held for disposal.

A blow down plug on the drain port will allow clean-out without removal of the screen, and without interrupting the process flow.

FEATURES & OPTIONS

  • Highly durable that makes it a part of various industrial applications
  • The affordable rates content our clients to the utmost level
  • Can be availed in customized specifications
  • Negligible maintenance
  • Easy cleaning or replacing the element.
  • Compact size and Low weight
  • Low Pressure drop across the filter.
  • Low Installation and maintenance.
  • With Drain Arrangement on request
  • Adequate strength of element and housing
  • Interchangeability of component with another of same type.
  • Wire mesh up to 5 Micron
  • Design & Testing International Standard

Availability

Availability [Size] : DN25 / 25MM / 1" To DN300 / 300MM / 12"


Y - Type Strainer
Availability [Size] : DN25 / 25MM / 1" To DN300 / 300MM / 12"
Body : CI / DI / WCB [CS] / CF8 [SS 304] / CF8M [SS 316] / CF3M [SS 316L]
Mesh : CF8 [SS 304] / CF8M [SS 316] / CF3 [SS 304L] / CF3M [SS 316L]
Pressure Rating : 125# / 150# / 300#
Face to Face : ND 40 STD.
Flange Drilling : ANSI 16.5 / BS 10 Table/ DIN / IS STD.
Screwed End : ANSI B 1.20.1 [BSP / NPT]
Socket Weld End : ANSI B 16.11
Butt Weld End : ANSI B 16.25
Pressure Rating : 125# / 150# / 300#
Design STD. : ANSI 16.34
Pressure Testing : API 598
